AVMATRIX SD1121-12G 1x2 12G-SDI Signal Repeater - Auto Detects SD/HD/3G/6G and 1 (Like New)
AVMATRIX SD1121-12G 1x2 12G-SDI Signal Repeater - Auto Detects SD/HD/3G/6G and 1 (Like New)
Couldn't load pickup availability
The AVMATRIX SD1121-12G Signal Repeater is a high-performance 1x2 SDI signal splitter and extender manufactured by LILLIPUT. This device automatically detects and supports all major formats including SD, HD, 3G, 6G, and 12G-SDI, as well as DVB-ASI signals, ensuring maximum compatibility. With one 12G-SDI Input and two 12G-SDI Outputs, it allows you to distribute a single source to two destinations without signal loss. It features automatic cable equalization and signal retiming to guarantee reliable, high-quality transmission up to a range of 60 meters (Data Transfer Rate: 12 Gigabits Per Second). The repeater passes all ancillary data and embedded audio. Power is conveniently supplied via 5V Micro USB. This unit (1 Count) is compatible with SDI Cameras, SDI Video Switchers, and SDI Monitors and features a detachable bracket for easy wall mounting.
Specifications:
- AVMATRIX SD1121-12G 1x2 12G-SDI Signal Repeater - Auto Detects SD/HD/3G/6G and 12G-SDI
- Input: 1x12G-SDI Output: 2x12G-SDI Automatically detects SD, HD, 3G, 6G, and 12G-SDI Support DVB-ASI signal
- Automatic cable equalization and signal retiming Pass all ancillary data and embedded audio
- 5V micro USB power Detachable bracket design for wall mounting
Technical Details:
Data Transfer Rate: 12 Gigabits Per Second
Brand: LILLIPUT
Manufacturer: LILLIPUT
Connector Type: Micro USB
Compatible Devices: SDI Cameras, SDI Video Switchers, SDI Monitors
Range: 60 Meters
Built-In Media: Cable
Unit Count: 1 Count
Item Weight: 156 Grams
